Feature:
• Full tab structure for safety.
• High safety.
• Excellent high and low-temperature performance.
• High charge and discharge rate
• Environmentally friendly
| Model | LY-40140 LFP |
| Nominal capacity | 20000mAh |
| Minimum capacity | 20000mAh |
| Nominal voltage | 3.2V |
| Internal resistance | Cell:≤3mΩ |
| Charge cut-off voltage(V) | 3.6V |
| Discharge cut-off voltage | 2.0V |
| Standard chamge method | 0.5C CC/Cv cut off 0.05C 0.5C |
| Standard discharge mode | 0.5C cc, cut off 2.0V 0.5C |
| Maximum continuous charge current | 0.2C |
| 0.5C | |
| 1.0C | |
| 0.5C | |
| Maximum continuous discharge current | 2C |
| Maximum pulse discharge current | 5C(10S) |
| Working temperature | 0-55°C |
| -20°C~+60°C | |
| Storage temperature | -10°C/+45°C |
| -10°C/+35°C | |
| Battery weight | 400±5g |
| Energy density | 160wh/Kg |
Find additional LFP 40140 options available at Lyrasom.
